Product features：
• UK made Electrochemical/Fuel cell sensor with high sensitivity and reliability；
• Rapid and convenient, Quick and Precise Analysis, do not need mouthpieces；
• When the concentration exceed the set point value, device will give Vibration Alarm；
• The function of electronic whistle makes the law enforcement more convinent and flexible；
• With Traffic baton and flashlight illumination function；
• Built in rechargeable lithium battery, ensuring more than 8 hours testing.
| Details | Technical Data | ||
| Principle of measurement | Electrochemical Sensor, alcohol-specific | ||
| Measurement Range | 0～150mg/100ml BAC | ||
| Test Mode | For quick testing, automatic sampling | ||
| Way of Breath Sample Extraction | Motor continuous air extraction, speed no less than 0.8L | ||
| Temperature range -operation | -5°C~45°C | ||
| Temperature range –storage | -30°C~70°C | ||
| Measuring Time | Adjustable( Minimum time: 1 second) | ||
| Working Pressure | 600~1400hPa | ||
| Temperature Humility | 45～85%r.h. | ||
| Screen | 1.3inch LCD Digital Screen | ||
| Continuous Working Time | More than 8 hours | ||
| Flashing Light | 2 lights of 3W | ||
| Vibration Alarm | When the concentration exceed the set point value, device will give Vibration Alarm | ||
| Test Item | Blowing distance 4-5cm | ||
| Test concentration（mg/100ml） | |||
| 20 | 40 | 150 | |
| Analyzing time | <5s | ||
| Clearing time | <15s | ||
| Measuring range | 15~35 | 35~65 | ＞80 |
| Sensitivity | The test concentration will be higher than 8mg/100ml at 20mg/100ml in the condition of 8-10cm blowing distance. | ||
