Product features:
• UK made Electronic/Fuel cell sensor: Highly specificity to alcohol,unaffected by other possible breath contaminants;
• Equipped with blowing interruption alarm prompt and refusal detection function;
• In the active mode, blowing gas from the mouthpieces will be emitted toward bottom shell of the device to prenvent gas directly face to the operator;
• Every test record can be transferred to PC data manage software in real time through 4G (GPRS) network enables real-time monitoring (Optional);
• License plate number, driving license number, police number and other necessary information can be entered and printed directly;
• Fingerprint identification(Optional);
• Intelligent voice broadcast function;
• Specially designed anti-suction one-way mouthpiece to ensure the accuracy during the test;
• Mouthpiece can be automatically ejected.
Details | Technical Data | |
Principle of measurement | Electrochemical Sensor, alcohol-specific | |
Measurement Range (BrAC) | 0.000mg/L~2.500 mg/L | |
Resolution | 0.001mg/L | |
Accuracy: Max. Measuring error, in relation to the ethanol standard | (-0.040~0)mg/L or Relative error -10%~0 | |
Repeatibility | ≤2.5% | |
Calibration | Every 6 months | |
Temperature range -operation | -10°C 〜50°C | |
Temperature range –storage | -30°C 〜70°C | |
Optimum Storage Conditions | Temperature:23℃±5℃ | |
Humidity:50%±30% | ||
Hydrocarbon concentration in the environment: no more than 0.002‰ | ||
Atmospheric pressure:ambient atmosphere pressure | ||
Other conditions:No vapor or electromagnetic disturbances in the environment are influencing the normal working conditions of the device | ||
Display | 3.2 inch TFT LCD color touch screen | |
PC Interface | USB (data can be transferred to a PC or printer) | |
Camera | 3.0 mega pixels, 120degree wild angle (optional) | |
Fingerprint identification | Fingerprint Input and matching (optional) | |
Voice broadcast | Intelligent voice broadcast | |
Printer | Built-in Micro Thermal printer/ Built-in Dot Matrix Printer (optional) | |
Dimension(L*W*T) | Approx. 195mm X 80mm X 38mm | |
Operation Voltage | State of charging | State of operation |
DC 10~14V | DC 6.3V~8.4 V | |
Batteries | 3000mAh/7.4 Lithium-ion-battery | |
Weight | Approx. 500g |
