Product features：
• Quick and Precise Analysis: 32bit embedded processor secures high performance of the system;
• UK made Electrochemical/Fuel cell sensor: Highly specificity to alcohol, unaffected by other possible breath contaminants;
• Data Handling Ability: Compact gas circuit design and advanced; analysis process assure fast, accurate and stable testing performance.
• Two testing modes: evidential and screening;
• All measurement functions are controlled via a single key.License plate number and driving license number can be input on touch screen；
• Practical Design: Thanks to its compact dimensions, the Panther-2 even fits into a shirt pocket. The ergonomic design makes the instrument equally easy to use for right and left-handed people；
• Specially designed one-way mouthpiece.
| Details | Technical Data | |
| Principle of measurement | Electrochemical Sensor, alcohol-specific | |
| Measurement Range (BrAC) | 0.000mg/L～2.500 mg/L | |
| Calibration | Every 6 months | |
| Temperature range -operation | -5°C 〜45°C | |
| Temperature range –storage | -30°C 〜70°C | |
| Display | 2.4 inch 320×240 dot matrix color touch screen | |
| Memory Capacity | Stores more than 4000 measured values with date and time （data can be transferred to a PC or printer） | |
| Number of Measurements per Battery Pack | More than 500 times (under ambient conditions) | |
| Dimension(L*W*T) | Approx.130mm X 55mm X 24mm | |
| Weight | Approx.177g | |
| Battery | 1200mAh/7.4V polymerized battery | |
